Features:
– Adjustable and secure mounting solution for roll cage setups
– Rubber sleeve protects mounting surface and provides increased grip
– Guided entry for 8mm socket driver or flat-head screwdriver to install
– Dual pivot arm with 180° vertical and 360° horizontal rotation
– Ball ends offer 180° / 60° movement for flexible positioning
– 75mm (3”) arm length with adjustable handle
– Pivot arm designed with preload tension for easy adjustability
– Inbuilt grooves for tidy cable management
– 316 stainless steel hardware with TPU overmould
– Lever Head offers patented dual-stage locking and portrait or landscape mounting orientation
Bar compatibility:
Suits all bar diameters from 32mm to 60mm (1-1/4” to 2-3/8”)
Fits RHS bar 35-50mm
Two pivot points for adjustability:
– Rotates through 180° vertically and 360° horizontally
– Balls at either end offer 180° / 60° movement for greater angle
Compatible With:
– Quad Lock 360 Range
– All Quad Lock Cases & Universal Adaptors
Not Compatible With:
– Non 360 Products
Included in box:
1x Quad Lock 360 Lever Head (with retention ring and M5 x 20mm countersunk hex head screw – Silver)
1x Dual Pivot Arm (Medium)
1x Dual Pivot Arm Handle
1x M5 x 35mm countersunk hex head screw – Silver
1x 3mm Hex (Allen) key
1x Hose Clamp Base (Assembled): Large hose clamp (40-60mm), Aluminium base, Spacer, Cap, Sleeve (Attached)
1x Sleeve (Spare)
1x Small hose clamp (21-44mm)
Materials:
Lever head:
– LEVER & INDEX BASE V3: Glass Filled Nylon
– FASTENER: 316 Stainless Steel (Silver)
Dual pivot arm (Medium):
– ARM: Glass Filled Nylon
– BALLS: TPU Overmould
– FASTENERS & HARDWARE: 316 Stainless Steel (Silver)
Hose clamp base:
– BASE: Aluminium 6061 T6
– CAP: Glass Filled Nylon
– SLEEVE & SPACER: Rubber (NBR/SBR)
– HARDWARE: 316 Stainless Steel (Silver
Dual pivot arm (Medium)
– Quad Lock 360 Dual Pivot Arm Handle / Screw Set (QLP-360-DPAH)
– Quad Lock 360 Dual Pivot Arm Balls – Set of 2 (QLP-360-DPAB)
– Quad Lock 360 Dual Pivot Arm – Medium (QLP-360-DPM)
Hose clamp base
– Quad Lock 360 Roll Cage Hose Clamp (QLP-360-HCB)
– No specific components available due to low product volume
– Future consideration – spare parts of the SPACER and SLEEVE
Measurements:
215 x 82 x 36mm (Varies by lever head assembly angle, DPM angle and hose clamp size used)
Specifikationer
Varumärke: Quad Lock
Artikelnummer: 292-QLM-RCM
GTIN / EAN: 9348943162883
Storlek: Mount
Vikt: 0.30 kg
